當前位置:首頁>新聞中心扭矩扳手檢定儀使用方法

扭矩扳手檢定儀使用方法

來源:http://brianstaruk.com日期:2022-07-15 發布人:admin

扭矩扳手檢定儀是檢定扭矩扳子、據矩起子的專用設備,主要用于檢測各種定力式扭力扳手,數顯式扭力板手、預置式扭力板手、等的儀器和產品。普遍應用于電氣制造、機械制造、汽車輕工和科研和檢測行業。

Torque wrench calibrator is a special equipment for calibrating torque wrenches and torque drivers. It is mainly used to detect various fixed torque wrenches, digital torque wrenches, preset torque wrenches, and other instruments and products. It is widely used in electrical manufacturing, machinery manufacturing, automotive light industry and professional scientific research and testing industries.
扭矩扳手檢定儀功用特性:
Functional characteristics of torque wrench calibrator:
1、高精度、高分辨率、采樣速度快、全屏顯現,7寸觸摸屏顯現。
1. High precision, high resolution, fast sampling speed, full screen display, 7-inch touch screen display.
2、采用高精度扭矩傳感器,具有扭矩方向顯現。
2. Adopt high-precision torque sensor, with torque direction display.
3、上下限值的設定,紅綠指示燈及峰鳴器聲光報警。
3. The setting of upper and lower limits, red and green indicators and audible and visual alarm of buzzer.
4、三種單位相互轉換,可供選擇(N·m、kgf·cm、Ib·in)。
4. The three units are interchangeable and can be selected (n · m, KGF · cm, IB · in).
5、實時、峰值、自動峰值三種形式可隨意切換。
5. Real time, peak and automatic peak can be switched at will.
6、采用儀表顯現、曲線顯現、曲線縮放功用、全觸摸屏顯現。
6. It adopts instrument display, curve display, curve zoom function and full touch screen display.
7、峰值堅持、自動解除功用、解除時間自在設定。
7. Peak persistence, automatic release function and release time can be set freely.
8、存儲大量測試數據。
8. Store a large amount of test data.
9、無操作自動關機功用,時間可自在設定。
9. Automatic shutdown function without operation, and the time can be set freely.
扭矩扳手檢定儀運用辦法:
Application method of torque wrench calibrator:
1、在運用扭矩扳手檢定儀之前,先檢查儀器電量能否充足,若電量缺乏,請先充電(充電時也可運用)。
1. Before using the torque wrench calibrator, check whether the power of the instrument is sufficient. If the power is insufficient, please charge it first (it can also be used during charging).
2、將被檢物的四方測頭放入該測試儀的承力四方孔內,同時運用的被檢物另一端的手柄在高度調理塊上方(若長度不夠時,可自在調理整套加載安裝)。
2. Put the square probe of the tested object into the bearing square hole of the tester, and at the same time, the handle at the other end of the tested object is above the height conditioning block (if the length is not enough, the whole set of conditioning can be loaded and installed freely).
3、翻開電源開關,顯現的扭矩值為零,假如不為零,則按清零鍵,將扭矩值清零。
3. Turn on the power switch, and the displayed torque value is zero. If it is not zero, press the reset key to reset the torque value.
4、測試前,需設置好上下限值、很小存儲值、很小峰值堅持值、自動峰值時間、自動關機時間、重力加速度等。
4. Before the test, it is necessary to set the upper and lower limit values, very small storage values, very small peak persistence values, automatic peak time, automatic shutdown time, gravity acceleration, etc.
1)上限值設定:用戶設定上限值,依據需求自在設定,到達上限值即自動聲光提示,上限值不高于滿量程。
1) Upper limit value setting: the user sets the upper limit value and sets it freely according to the demand. When the upper limit value is reached, it will be prompted automatically by sound and light, and the upper limit value is not higher than the full range.
2)下限值設定:用戶設定下限值,依據需求自在設定,到達下限值即自動燈光提示,下限值不得高于設定的上限值。
2) Lower limit value setting: the user sets the lower limit value and sets it freely according to needs. When the lower limit value is reached, the automatic light prompt is given, and the lower limit value shall not be higher than the set upper limit value.
3)很小存儲值設定:用戶依據存儲需求設定很小存儲值,小于該值的數據將不被貯存。
3) Very small storage value setting: the user sets a very small storage value according to the storage demand, and the data less than this value will not be stored.
4)很小峰值堅持值設定:用戶依據峰值,自動峰值丈量需求自在設定,小于該值的數據不被峰值保管。
4) Small peak value setting: the user can set the automatic peak measurement demand according to the peak value, and the data less than this value will not be kept by the peak value.
5)自動峰值時間設定:用戶依據自動峰值丈量狀態下峰值需求堅持的時間從1秒~99秒自在設定。
5) Automatic peak time setting: the user can freely set the time from 1 second to 99 seconds according to the peak demand under the automatic peak measurement state.
6)自動關機時間設定:無操作狀態下,自動關機時間從0分鐘~9分鐘可自在設定(當設置為0分鐘則表示為解除自動關機)。
6) Automatic shutdown time setting: when there is no operation, the automatic shutdown time can be freely set from 0 minutes to 9 minutes (when it is set to 0 minutes, it means that the automatic shutdown is cancelled).
7)重力加速度設定:用戶可依據本地域的位置設定重力加速度值。
7) Gravity acceleration setting: the user can set the gravity acceleration value according to the position of the local domain.
8)恢復初始設置:用戶操作不當或屢次更改數據呈現紊亂,能夠經過此項設置來把1~7的數據恢復到出廠狀態。
8) Restore the initial setting: if the user operates improperly or changes the data repeatedly, the data of 1 ~ 7 can be restored to the factory state through this setting.
以上就是為大家介紹的有關扭剪型電動扳手的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務.http://brianstaruk.com
The above is a detailed introduction about the torsion shear electric wrench, which I hope will be helpful to you If you have any questions, please contact us We will provide you with professional service http://brianstaruk.com
